DescriptionADAM Audio T8V Studio Monitor Speaker DetailsThe T8V is an affordable, professional 2-way powered studio monitor with an 8˝ woofer and ADAM Audio’s latest addition to the T Series.The T8V impresses with a multitude of features that bring real benefits to the user: The U-ART tweeter’s 4:1 velocity transfer ratio, in combination with the new Class D amplifiers’ high dynamic range, yield respective max. peak SPL of 118 dB per pair. The tweeter, which extends up to 25 kHz, works as a team with the HPS Waveguide. This allows an optimal radiation of the high frequencies, which means the advantage of a more controlled, larger usable sweet spot during monitoring. With a bass extension down to 33 Hz, the T8V is especially suitable for users who produce bass-heavy music.The T8V is the perfect studio speaker for those who have always wanted to work with an 8“ monitor from ADAM Audio, but where budgets have been insufficient.FeaturesU-ART 1.9” Accelerated Ribbon Tweeter with HPS WaveguidePolypropylene 8” woofer and rear-firing bass-reflex portTotal RMS Amp. Power: 90 WFrequency Response: 33 Hz – 25 kHz (-6 dB)Max. SPL Per Pair at 1 m: ≥118 dBSpecificationsGeneral DataPanel: RearMax. Power Consumption: 150 WWeight: 21.6 lbs (9.8 kg)Height x Width x Depth: 15.8″ x 9.8″ x 13.2″ (400 mm x 250 mm x 335mm)Audio Input ConnectorsAnalog: XLR / RCAInput Impedance: 10 kOhm / 20 kOhmAmplification:WooferAmplifier Type: PWMAmp. Power RMS: 70 WTweeterAmplifier Type: PWMAmp. Power RMS: 20 WAcoustics:Frequency Response: 33 Hz – 25 kHz (-6 dB)THD > 80 Hz: 0.5 %Max. SPL per pair at 1 m: ≥118 dBCrossover Frequency: 2.6 kHzDrivers:WooferBasket Diameter: 8″Voice Coil Diameter: 1″Cone Material: PolypropyleneTweeterType: U-ARTDiaphragm Area: 4 inch² (2420 mm²)Equiv. Diaphragm Diameter: 1.9″ (48 mm)Velocity Transform Ratio: 4 to 1Diaphragm Weight: 0.17 gWaveguide: HPSControl Options:Input Sensitivity: -10 to 4 dBGain: YesHigh Shelf EQ > 5 kHz: – 2 dB, 0 dB, 2 dBLow Shelf EQ < 300 Hz: – 2 dB, 0 dB, 2 dB In the boxADAM Audio T8V Studio Monitor SpeakersPower cordQuick Start Guide
